Westfall Applies 3D Printing to Manufacture of Their Low Headloss Pipe Static Mixer 3050

Pipe and patented Mixing Vane inserts emerge from 3D printing as a preassembled Static Mixer that is glued inside a PVC pipe.

Westfall Low Headloss Pipe Static Mixer 3050 Insert

Westfall Manufacturing has pioneered the manufacture of small size Static Mixers, specifically their Low Headloss Pipe Static Mixer 3050, by 3D printing their patented mixer out of durable nylon and gluing it in PVC pipe.

This innovation comes in response to customers who asked for Low Headloss Mixer 3050 in the 1” to 5” (0.95cm to 21.7cm) range, which is too small for cost-effective fiberglass or stainless steel custom fabrication.

"For mixing low velocity, low viscosity water and gases, durable 3D printed inserts are the wave of the future. For mixing high velocity and high viscosity fluids, durable 3D printed stainless steel inserts are the wave of the future. Either way, 3D printing makes our high performance Static Mixers more affordable to customers around the world."

Bob Glanville , CEO, Westfall Manufacturing Co.

Westfall engineers knew that whether the materials used were metal, fiberglass or 3D printed nylon, the mixer’s high performance wouldn’t change. If the geometry stayed the same the hydrodynamics would be the same.

The durable nylon inserts withstand steady exposure to harsh chemicals from caustics to gas and oil. 3D printed inserts can be made from a variety of materials, from Kynar to stainless steel.

The addition of 3D printing to Westfall’s manufacturing ability means that customers can order Static Mixers in small sizes and receive rapid, cost-effective delivery.

Because of K-Values ranging from 0.58 to 1.64, Westfall’s Model 3050 causes 2 to 4 times less headloss than other mixers.

These mixers offer an important solution for municipal and industrial water and wastewater treatment, oil, gas, natural gas, propane and biofuel processors.

Additional Information:  WestfallStaticMixers.com

Robert Glanville 401 465 9784

Source: Westfall Manufacturing Co.

Share:


Tags: High Performance Mixing, Motionless Mixing, Wastewater Purification, Wastewater Treatment


Additional Images

About Westfall Manufacturing

View Website

Westfall Manufacturing is a small company in a small state that designs and delivers smart motionless mixers for pipeline installations around the world. They specialize in oversize static mixers that cause 2 - 4 times less headloss than competitors.
